6S LTO Battery Balancer 1A 3.5A 5.5A Active Equalizer For 14.4V Yinlong 66160 Battery

6S LTO Battery Balancer Active equalizer 1A 3.5A 5.5A For 14.4V Yinlong 66160 Battery

LTO version
Balance start voltage: 2.0V-2.8V

Balance stop voltage: 1.9V (undervoltage sleep state)

Maximum Balance current: The whole group error is 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)

5S LTO static current Full state: 2.8v*5cell) 14V 12mA
6S LTO static current Full state: 2.8v*6cell) 16.8V 15mA

External power supply is required: no external power supply is required, and the internal energy transfer make the whole battery pack in balance .
Working environment temperature: 0-60 degrees

Before balancing VS After balancing

The effect of active and passive balancer before and after balancing.

Active balancer VS Passive balancer

Active balancer is More avdanages than passive balancer.

Active balancer work range

Active balancer can balance in the charge and discharge and storage.
