24V 8S Battery Balancer For LiFePO4 Li Polymer Li Ion LTO 18650 DIY Battery Equalizer

Brand Name:	EJ
Model Number:	EJ-QNBBM-8S
MOQ:	2
Price:	€105.12-113.88

Detail Information

Product Description

Detail Information

Place of Origin:

China

Application:

EV,UPS,SOLAR

Weight:

0.9KG

Composed Type:

8S LiFePO4 Lithium LTO Li-ion

Size:

150 * 140 * 25 Mm

Voltage:

2V-5V/cell

Type:

For Li-ion

Highlight:

24V 8S Battery Balancer

LTO 8S Battery Balancer

18650 DIY Battery Equalizer

Product Description

Advantages	Up to 6 A Continuous Balancing Fit for 50-1000AH Unlimited Cell Count LiFePO4-Li-Ion-Li-Polymer-Lithium Can balance during charging, discharging, and storage Keeps your Batteries Voltage difference Within 10mV
Size	150 * 140 * 25 mm
Function	Balance for Li-ion Lithium,LiFePO4 battery pack
Related Product	There are other models for optional,such as 4S,5S,6S,7S,8S etc

8S Lithium Battery Balancer For 24V LiFePO4 Li-Polymer Li-ion LTO 18650 DIY Active equalizer Winston Thundersky CALB BYD

Features:
1. High-frequency pulse, dynamic battery voltage-amperage balancer
2.Simple wiring and high efficiency
3.Works with all charger amperage and voltage inputs
4.All 1S Single Balancers come with the interconnecting and battery wiring
5.0.5m/1.5ft maximum suggested wire length for all the multiple series balancers. (35m 4S, 5S,6S, 8S)
6.Idle Current Draw is <50mW
7.Series modules(work with 4, 5, 6, or 8 batteries in series)

Benefits:
1.Quick and easy installation.
2. Keeps your batteries voltage difference within 10mV.
3.Increase 2-3 times lifespan for battery pack.

BATTERY AH LIMITS	50-1000AH
LITHIUM BATTERY VOLTAGE LIMITS	2V ~ 5V
BATTERY COUNT LIMIT	8S-Unlimited
BMS LIMIT	Can work with BMS or can work independently
BATTERY TYPE	Li-ion,Li-polymer,LiFePO4,
BALANCER CONFIGURATION	Series and Paralleled
VOLTAGE DIFFERENCE AFTER USING THE BALANCER	<10mV
VOLTAGE DIFFERENCE VS. BALANCE CURRENT	300mV-1A; 1V-3A
POWER CONSUMPTION	<50mW per 1S
BALANCING	High to Low
WORKS DURING CHARGE	Yes
WORKS DURING DISCHARGE	Yes
WORKS DURING STORAGE	Yes
BALANCING AMPERAGE	6-10A
CONTINUOUS BALANCING AMPERAGE	6A
MAX BALANCING AMPERAGE	10A
BALANCE ACCURACY (%)	0.5
BALANCE METHOD	Energy Transfer & Dynamic
WORKING EFFICIENCY WHEN BALANCE CURRENT IS 1A	>94%
RELATIVE HUMIDITY (%)	45-90%
WORKING ENVIRONMENT	Low Humidity
WORKING TEMP (C)	-40 to 80
STORAGE TEMP (C)	-40 to 100

Product Usage

Before balancing VS After balancing

The effect of active and passive balancer before and after balancing.

Active balancer VS Passive balancer

Active balancer is More avdanages than passive balancer.

Active balancer work range

Active balancer can balance in the charge and discharge and storage.
