| Brand Name: | JK |
| Model Number: | EJ-JKB1A24S/B2A24S/B5A24S/B10A24S |
| MOQ: | 10 |
| Product model | JK-B2A24S |
| Dimensions | 162x100x20MM |
| Active balancing current | 0.1~2A adjustment |
| Cell voltage range | 1V~5V±5MV |
| Cell voltage difference after balancing | ≤5MV |
| Power supply range | 40V~100V |
| Operating temperature | -30℃~90℃ |
| Balancing method | Energy transfer active balancing technology |
| Balancing start condition | Balancing starts automatically when the voltage difference exceeds the trigger value (settable), and starts automatically when it is >10MV by default |
| Applicable battery string number | 2~24 battery packs |
| Applicable battery types | Support all types of batteries such as Li-ion, iron lithium, lead acid, LTO, super capacitors, etc. |
| Balancing cascade | Support, applicable to battery packs with more than 24 strings, theoretically unlimited cascading |
| Bluetooth communication function | Standard Bluetooth communication, optional 485, CAN |
| Power consumption | Balancing state 10MA@100V, non-balanced state 6MA@100V |
