| Brand Name: | E&J |
| Model Number: | EJ12100FEB-H |
| MOQ: | 4 |
Parameters/ Models | 50Ah | 60Ah | 100Ah | |
Electric | Nominal voltage | 12.8V | 12.8V | 12.8V |
Nominal capacity | 50Ah | 60Ah | 100Ah | |
Stored energy | 640Wh | 768Wh | 1280Wh | |
Cold Cranking Amps (CCA) | 700 | 900 | 1500 | |
Internal resistance | ≤ 50mΩ | ≤ 50mΩ | ≤ 50mΩ | |
Cycles | >5000 cycles | >5000 cycles | >5000 cycles | |
Self discharge | < 3% per month | < 3% per month | < 3% per month | |
Energy efciency | > 96% | > 96% | > 96% | |
Standard Charge | Charge voltage | 14.6V ± 0.1V | 14.6V ± 0.1V | 14.6V ± 0.1V |
Charge mode | CC/CV : Constant Current / Constant Voltage | CC/CV : Constant Current / Constant Voltage | CC/CV : Constant Current / Constant Voltage | |
Maximum continuous charge current | 20A/ 50A | 20A/50A | 30A/100A | |
BMS charge cut-off voltage | 60.8V ± 0.1V | 60.8V ± 0.1V | 60.8V ± 0.1V | |
Standard Discharge | Continuous discharge current | 50A | 60A | 100A |
BMS discharge cut-off voltage | 14.8V ± 0.1V | 14.8V ± 0.1V | 14.8V ± 0.1V | |
Environment | Charge temperature range | 0°C- 45°C @60±25% | 0°C- 45°C @60±25% | 0°C- 45°C @60±25% |
Discharge temperature range | -20°C – 60°C @60±25% | -20°C – 60°C @60±25% | -20°C – 60°C @60±25% | |
Storage temperature | 0°C – 40°C @60±25% | 0°C – 40°C @60±25% | 0°C – 40°C @60±25% | |
IP protection level | IP65 | IP65 | IP65 | |
Mechanical | Cell assembly | Prismatic | Prismatic | Prismatic |
Casing material | ABS | ABS | ABS | |
Weight | 6kg | 8kg | 11.5 kg | |
Terminal | M8 | M8 | M8 | |
