| Brand Name: | E&J |
| Model Number: | EJ1260FEB-H |
| MOQ: | 4 |
|
Parameters/ Models
|
50Ah
|
60Ah
|
100Ah
|
|
|
Electric
|
Nominal voltage
|
12.8V
|
12.8V
|
12.8V
|
|
Nominal capacity
|
50Ah
|
60Ah
|
100Ah
|
|
|
Stored energy
|
640Wh
|
768Wh
|
1280Wh
|
|
|
Cold Cranking Amps (CCA)
|
700
|
900
|
1500
|
|
|
Internal resistance
|
≤ 50mΩ
|
≤ 50mΩ
|
≤ 50mΩ
|
|
|
Cycles
|
>5000 cycles
|
>5000 cycles
|
>5000 cycles
|
|
|
Self discharge
|
< 3% per month
|
< 3% per month
|
< 3% per month
|
|
|
Energy efciency
|
> 96%
|
> 96%
|
> 96%
|
|
|
Standard Charge
|
Charge voltage
|
14.6V ± 0.1V
|
14.6V ± 0.1V
|
14.6V ± 0.1V
|
|
Charge mode
|
CC/CV : Constant Current / Constant Voltage
|
CC/CV : Constant Current / Constant Voltage
|
CC/CV : Constant Current / Constant Voltage
|
|
|
Maximum continuous charge current
|
20A/ 50A
|
20A/50A
|
30A/100A
|
|
|
BMS charge cut-off voltage
|
60.8V ± 0.1V
|
60.8V ± 0.1V
|
60.8V ± 0.1V
|
|
|
Standard Discharge
|
Continuous discharge current
|
50A
|
60A
|
100A
|
|
BMS discharge cut-off voltage
|
14.8V ± 0.1V
|
14.8V ± 0.1V
|
14.8V ± 0.1V
|
|
|
Environment
|
Charge temperature range
|
0°C- 45°C @60±25%
|
0°C- 45°C @60±25%
|
0°C- 45°C @60±25%
|
|
Discharge temperature range
|
-20°C – 60°C @60±25%
|
-20°C – 60°C @60±25%
|
-20°C – 60°C @60±25%
|
|
|
Storage temperature
|
0°C – 40°C @60±25%
|
0°C – 40°C @60±25%
|
0°C – 40°C @60±25%
|
|
|
IP protection level
|
IP65
|
IP65
|
IP65
|
|
|
Mechanical
|
Cell assembly
|
Prismatic
|
Prismatic
|
Cylindrical
|
|
Casing material
|
ABS
|
ABS
|
ABS
|
|
|
Weight
|
6kg
|
8kg
|
11.5 kg
|
|
|
Terminal
|
M8
|
M8
|
M8
|
|
