| Brand Name: | EJ |
| Model Number: | EJ-12100LFP |
| MOQ: | 1 |
| Price: | AED 862.31-1,046.99 |
• High lifespan: two thousand cycles and more (see chart)
• Deep discharge allowed up to 100 %
• Ultra safe Lithium Iron Phosphate chemistry (no thermal run-away, no fire or explosion risks)
• Embedded BMS (Battery Management System): improve lifespan AND secure the battery
• No Lead, no heavy metal, no toxic element
• Calendar life > 10 years
• Excellent temperature robustness (-20 °C up to +60 °C)
• Constant power during discharge (very low internal resistance)
• Very low Peukert’s losses (energy efficiency >96 %)
• Very low self-discharge (<3 % per month)
• No memory effect
• About 50 % lighter and 40% smaller than equivalent Lead-AGM battery with same usable energy
Prismatic Battery cells cylindrical battery cell BMS Empty battery case
|
Technical Specifcations
|
||
|
Electric
|
Nominal voltage
|
12.8V
|
|
Nominal capacity
|
100 Ah
|
|
|
Stored energy
|
1280 Wh
|
|
|
Internal resistance
|
≤ 50mΩ
|
|
|
Cycles
|
>2000 cycles (see chart)
|
|
|
Self discharge
|
< 3% per month
|
|
|
Energy efciency
|
> 96%
|
|
|
Standard Charge
|
Charge voltage
|
14.6V ± 0.1V
|
|
Charge mode
|
CC/CV : Constant Current / Constant Voltage
|
|
|
Maximum continuous charge current
|
10A/ 20A
|
|
|
BMS charge cut-off voltage
|
14.8V ± 0.1V
|
|
|
Standard Discharge
|
Continuous discharge current
|
50 A
|
|
Maximum discharge current (30s)
|
100 A
|
|
|
BMS discharge cut-off voltage
|
10 V
|
|
|
Environment
|
Charge temperature range
|
0°C- 45°C @60±25%
|
|
Discharge temperature range
|
-20°C – 60°C @60±25%
|
|
|
Storage temperature
|
0°C – 40°C @60±25%
|
|
|
IP protection level
|
IP56
|
|
|
Mechanical
|
Cell assembly
|
Cylinder
|
|
Casing material
|
ABS
|
|
|
Dimensions
|
L : 300mm x W : 173mm x H : 216 mm
|
|
|
Weight
|
13kg
|
|
|
Terminal
|
